The Mercury 60HP Long Shaft EFI ELPT is a 60-horsepower four-stroke outboard built around Mercury’s 995cc inline-four platform. This configuration combines electronic fuel injection, electric starting, remote mechanical steering and a 20-inch long shaft for boats designed around a standard long-transom installation. With a 5,500–6,000 RPM full-throttle range and a 252 lb listed dry weight, it is a practical mid-range outboard option for recreational, fishing and utility boats where dependable four-stroke power and straightforward remote control are important.

Mercury 60HP Long Shaft EFI ELPT Overview

This Mercury 60ELPT uses a naturally aspirated inline-four four-stroke engine with 995cc of displacement. Mercury’s published specifications identify the 60HP model as a four-cylinder engine with a 5,500–6,000 RPM full-throttle operating range and 18 amp / 226 watt alternator output. The EFI fuel system is designed for controlled fuel delivery, while electric starting and remote mechanical steering suit boats equipped for console or remote-control operation.

Key Specifications

• Model: Mercury 60ELPT
• Engine type: Inline 4-cylinder four-stroke
• Horsepower: 60 HP
• Displacement: 995cc
• Cylinders: 4
• Fuel system: Electronic Fuel Injection (EFI)
• Fuel induction: 8 valves total, two valves per cylinder
• Shaft length: 20 inches / long shaft
• Steering: Remote mechanical
• Starting: Electric
• Alternator: 18 amp / 226 watt
• Full-throttle RPM range: 5,500–6,000 RPM
• Listed dry weight: 252 lbs

Long-Shaft 20-Inch Transom Fitment

The 20-inch shaft is an important fitment specification. Before purchasing or installing this Mercury 60HP outboard, confirm your boat’s recommended transom height and the correct shaft length for the hull. A long-shaft motor should not be selected solely by horsepower; the engine mounting height, transom design, steering arrangement and propeller setup all affect how the finished installation performs.

EFI Four-Stroke Performance

The 995cc inline-four layout gives this Mercury 60HP a substantial displacement for a 60-horsepower outboard. Electronic fuel injection provides metered fuel delivery, while the four-stroke design is suited to boat owners looking for a modern gasoline outboard for regular recreational or utility use. The published 5,500–6,000 RPM full-throttle range is also an important reference when selecting the propeller and checking the final installation setup.

Electrical Output and Controls

The listed 18 amp / 226 watt alternator provides charging capacity for the boat’s electrical system. The electric-start configuration is intended for remote-control installations, and the product specifications identify remote mechanical steering. The ELPT configuration is also associated with power trim and tilt on this model family, but the exact rigging and controls supplied with an individual engine should be confirmed before purchase.

Who This Mercury 60HP Outboard Is Suited For

This Mercury 60HP long-shaft outboard can be considered for fishing boats, recreational runabouts, utility boats and other hulls designed for approximately 60 horsepower. The right application depends on the boat manufacturer’s maximum horsepower rating, transom dimensions, target operating load and required shaft length. For repower projects, compare the existing engine’s shaft length, control system, steering arrangement, mounting pattern and electrical requirements before replacing it.

Installation and Repower Considerations

• Confirm that the boat is rated for a 60HP outboard before installation.
• Verify that a 20-inch shaft is appropriate for the boat’s transom.
• Check steering and remote-control compatibility before ordering rigging components.
• Confirm the required propeller specification after considering hull design, load and intended operating conditions.
• Verify that the engine reaches Mercury’s recommended 5,500–6,000 RPM range at wide-open throttle with the finished boat setup.
• For repowers, inspect the transom, steering, fuel system, battery and electrical connections before commissioning the replacement engine.

Mercury 60HP Long Shaft EFI ELPT FAQs

How much horsepower does the Mercury 60ELPT produce?

The Mercury 60ELPT is rated at 60 horsepower, with a 995cc displacement and four cylinders.

What is the shaft length of this Mercury 60HP?

This product is specified with a 20-inch long shaft. Confirm the required shaft length against the boat’s transom before purchasing.

Is the Mercury 60ELPT fuel injected?

Yes. The engine uses Electronic Fuel Injection (EFI), with an 8-valve configuration across its four cylinders.

What is the displacement of the Mercury 60HP?

The displacement is 995cc. The 60HP four-stroke uses a four-cylinder inline configuration.

What RPM range should the Mercury 60HP reach at full throttle?

The specified full-throttle operating range is 5,500–6,000 RPM. Final RPM should be checked on the installed boat because propeller selection, hull design and operating load affect engine speed.

Is the Mercury 60ELPT suitable for a repower?

It can be a repower option when the boat is rated for 60 horsepower and the 20-inch shaft, steering, controls, mounting and electrical requirements are compatible. The boat manufacturer’s specifications should always be checked before installation

For another Mercury 60HP option, compare the 2022 Mercury 60HP Outboard or browse the outboard engine collection..
